Why Using CISC Xplorer Inline -
for Boosting RFID Production

We Master the Top 10 Pain Points for High-Volume Manufacturers

The system eliminates „missed writes“ by using a Communication Interface Unit (CIU) that synchronizes directly with the production machine’s pulse (encoder signals). This ensures the hardware knows the exact position of the tag at all times. The system doesn’t move to the next step until it receives a hardware-level confirmation that the „write“ command was successful and verified.

The Xplorer Inline goes beyond simple „pass/fail“ logic. It performs a high-speed RF performance measurement, checking the sensitivity and backscatter of each inlay. By identifying „weak“ tags that meet minimum standards but fall below a quality threshold, the system can trigger a reject signal before those tags ever reach a consumer, ensuring only high-performance silicon leaves the factory.

While complex operations like AES encryption or permanent locking require more „airtime,“ the Xplorer utilizes high-performance processors and optimized protocol stacks designed for high-speed crypto-handshakes. This allows you to maintain maximum throughput without sacrificing the security of the data or being forced to slow down the conveyor belt.

The system is built on a flexible, vendor-agnostic platform. It fully supports the command sets for NXP, Impinj and EM Microelectronic. All inlays are compatible, including those from Avery Dennison, HID, Arizon RFID, Checkpoint and SML.

The Xplorer Inline is available for RAIN or NFC applications. It offers high-speed encoding and user-friendly operation to enable high-throughput RFID production.

To prevent „bleeding“ into adjacent tags, the system uses near-field focused antennas and precise power control. By narrowing the RF field to a specific millimeter-range zone and utilizing high-speed shielding techniques, the system ensures it only communicates with the tag directly in the „target zone,“ even on high-density rolls.

The software provides real-time, comprehensive data logging for every shift. Management can export detailed reports showing the total units processed, the specific reason for any QA failures (e.g., low sensitivity vs. encoding error), and final successful yields. These logs serve as a „digital birth certificate“ for compliance and customer audits.

The integrated software handles the heavy lifting of data formatting. It automatically converts raw serial numbers from your CSV or SQL database into GS1-compliant formats (like SGTIN-96). It calculates the necessary headers, filter values, and check-digits on the fly, removing the risk of manual encoding errors.

The hardware is designed for industrial environments with a compact footprint and modular antenna mounts. It supports standard industrial protocols allowing it to „talk“ directly to your existing PLCs. This ensures the Xplorer works in perfect harmony with your current converting or printing equipment.

The system utilizes dynamic speed compensation. By constantly monitoring real-time data from web sensors and encoders, the Xplorer adjusts its communication timing instantly. Whether the line is ramping up, slowing down, or running at a steady state, the system maintains the exact timing required for a perfect encode every time.

Production Demands vs. Technical Mastery

The Xplorer Inline Advantage

Customer Requirement Xplorer Inline Technical Specification The Benefit to the Customer
High-Speed Accuracy Controllable Interface Unit (CIU) with hardware-timed trigger logic. Maintains 100% data integrity even at line speeds exceeding 300,000 UPH.
Yield & QA Real-time RF Performance Testing (Sensitivity and Backscatter measurements). Automatically identifies and flags "weak" tags that would fail in the field, ensuring 100% functional yield.
Encryption/Crypto SAM & TAM Support with high-speed protocol optimization for AES. Executes complex security handshakes and locking commands without forcing a line slow-down.
Chip Flexibility Full support for ISO/IEC 18000-63 (RAIN) and ISO/IEC 14443/15693 (NFC). Future-proof; compatible with all major ICs from NXP, Impinj, Alien, and STMicroelectronics.
Cross-Talk Prevention Specialized Shielded Near-Field Antennas and adjustable power levels. Ensures the RF field is focused only on the target tag, preventing accidental "over-writes" of adjacent labels.
Data Translation Integrated GS1 SGTIN-96 / 198 and ISO data formatting engines. Plug-and-play data handling; converts standard CSV/SQL databases into compliant RF memory banks automatically.
Integration Ease Modular design with REST API, LLRP, and Industrial Ethernet connectivity. Easily mounts onto existing machines (Melzer, Mühlbauer, Bielomatik, etc.) and talks to existing PLCs.
Speed Compensation Encoder-based synchronization (Rotary encoder input). The system "listens" to the machine's heart rate; if the line speeds up or slows down, the encoding timing adjusts instantly.
Yield Reporting Automated Production Logs (PDF/CSV) with individual tag performance metrics. Provides a "Birth Certificate" for every reel produced, which can be shared with end-customers as a guarantee of quality.
Dual-Frequency Optional Multi-Protocol heads for concurrent RAIN and NFC processing. Handles complex "hybrid" tags in a single pass, reducing hardware footprint and production complexity.

Production Checklist: The Xplorer Inline Standard

Feature Standard Encoding CISC Xplorer Inline
Throughput Limited by printer/manual speed > 300k Units Per Hour
QA Integration Separate step (often skipped) Integrated (Test + Encode + Lock).
Data Handling Manual Hex input required Automatic (SGTIN / ISO formats)
Speed Sync Fixed speed Auto-syncs to machine speed (CIU)
Security Open encoding Encrypted / Crypto support

Mastering the Market:
Expertise to Fuel Your Business Growth

The CISC Glossary

Categories:

Kategorie
  • BLE (Bluetooth Low Energy) & IoT (10)
  • Performance & Measurement Metrics (10)
  • Regulatory & Standards (10)
  • CISC Hardware & Product Family (13)
  • Supply Chain & Data Integration (14)
  • RFID & RAIN General (16)
  • Production & Software Logic (28)

Key Terms:

Key Term
  • Aviation (1)
  • Logistics (1)
  • WLC (3)
  • RFID (9)
  • BLE (11)
  • Hardware (11)
  • NFC (12)
  • RAIN (12)
  • Software (13)
  • Standard (14)
  • General (22)
search

100% Quality Assurance:

The requirement that every single tag is tested, not just samples.

  • General

Active RFID:

Tags that have their own battery and transmitter to broadcast signals (long range).

  • RFID

Advertising Interval:

How often a beacon broadcasts its signal (influences battery life).

  • BLE

Antenna Tunnel:

An RF-shielded zone on a production line to isolate the tag being measured.

  • Hardware

Anti-Collision:

Algorithms that allow a reader to talk to thousands of tags simultaneously.

  • General

AoA (Angle of Arrival):

Advanced method using multiple antennas to find a beacon’s exact location (sub-meter accuracy).

  • BLE

API (Python/C#):

Interface for custom automation scripts to control CISC hardware.

  • Software

ASN (Advance Shipping Notice):

A digital list sent to a customer before the truck arrives.

  • Software

Asset Tracking:

Using tags to monitor the location of equipment, tools, or containers.

  • General

Backlink (BLF):

The speed of tag-to-reader data transmission (e.g., 640 kHz).

  • RAIN

Backscatter Power:

The signal strength reflected by a tag back to the reader.

  • RAIN

Batch Reporting:

Generation of data logs (CSV/PDF) for quality auditing.

  • Software

Beacon:

A small transmitter that broadcasts a unique ID to nearby smartphones or gateways.

  • BLE

Bistatic Setup:

Using separate antennas for transmit and receive (higher sensitivity).

  • General

BLE Gateway:

A bridge device that „hears“ BLE beacons and sends their data to the cloud via Wi-Fi/LTE.

  • BLE

BLE Xplorer Inline:

Solution for high-speed QA of BLE-based IoT Pixels and active tags.

  • BLE

Bonding/Pairing:

The process of two BLE devices exchanging security keys to communicate privately.

  • BLE

Circular Polarization:

Antenna type that sends waves in a corkscrew, good for tags at any angle.

  • Hardware

CISC Test Antenna:

Precision-calibrated antennas (Circular/Linear) for repeatable RF results.

  • Hardware

CIU (Controllable Interface Unit):

Hardware bridge connecting the system to industrial encoders and triggers.

  • Hardware

Cold Chain:

Tracking temperature-sensitive goods (vaccines/food) using RFID sensor tags.

  • Logistics

Cycle Counting:

Using RFID to quickly audit inventory without stopping operations.

  • General

Detuning:

When metal or liquid near a tag shifts its frequency, making it unreadable.

  • General

Differential RCS:

Radar Cross Section; a measure of how effectively a tag scatters energy.

  • General

Dry Inlay:

An inlay without adhesive, typically on a continuous PET carrier.

  • RFID

Dwell Time:

How long an asset stays in a specific location (e.g., „Pallet stayed in Dock 4 for 3 days”).

  • General

Eddystone:

Google’s open-source protocol for BLE beacons.

  • BLE

EDI (Electronic Data Interchange):

The standard for business-to-business document exchange (orders/shipments).

  • Software

Encoder Wheel:

A rotary sensor that tracks physical web movement for precise test/mark positioning.

  • Hardware

Encoding & Locking:

High-speed writing and permanent securing of data (like EPC) to tag memory.

  • Software

EPC (Electronic Product Code):

A unique identifier for every single physical item in the supply chain.

  • Standard

EPC Gen2 V2:

Global air interface protocol for RAIN RFID

  • Standard

EPC Gen2v3:

The newest GS1/RAIN air interface protocol (ratified 2024), featuring reduced tag clutter,
faster inventory commands, and enhanced security.

  • Standard

EPCIS:

The standard for sharing „Who, What, Where, Why“ event data across a supply chain.

  • Standard

ETSI EN 302 208:

European regulatory limits for power and frequency

  • Standard

Fail Marking:

Physically flagging (ink/punch) a defective tag on a production reel.

  • Hardware

FCC Part 15:

US RF regulatory standards for device interference.

  • Standard

FOD (Foreign Object Damage):

Preventing tools or trash from being left in aircraft via RFID tracking.

  • Aviation

Foreign Object Detection (FOD):

Detecting metal that could overheat during wireless charging.

  • NFC, WLC

Frequency Sweep:

Rapid check of performance across the entire UHF (800–1000 MHz) or HF band.

  • General

GATT (Generic Attribute Profile):

The way BLE devices organize and send data to each other.

  • BLE

GPIO:

Physical pins used to trigger tests or signal „Fail“ markers on a conveyor line.

  • Hardware

Grey Market Tracking:

Using RFID to ensure products are only sold in authorized regions.

  • General

GS1 TIPP:

Retail performance grading protocol for tagged items.

  • Standard

GTIN (Global Trade Item Number):

The standard GS1 code for a product type (used in barcodes).

  • Standard

GUI:

 Graphical User interface

  • Software

H-Field Strength:

Magnetic field strength ($A/m$) required to power an NFC device.

  • NFC

iBeacon:

Apple’s proprietary protocol for BLE proximity sensing.

  • BLE

Inlay:

The „bare“ RFID tag (chip + antenna) before it is converted into a finished label.

  • RFID

Interoperability Testing:

Ensuring tags work across multiple reader manufacturers.

  • General

IQ Data Export:

Exporting raw RF signals for deep forensic analysis.

  • Software

ISO/IEC 14443:

Core standard for Proximity (NFC) cards and tags.

  • Standard

ISO/IEC 18046-3:

International performance test methods for RFID.

  • Standard

Latency Compensation:

Algorithms ensuring markers hit the correct tag despite line speed shifts.

  • Software

Line of Sight (LoS):

A direct path between the reader and tag (required for Barcode, not for RFID).

  • General

Linear Polarization:

Antenna type that sends waves in one plane; offers longer range but requires alignment.

  • Hardware

Load Modulation:

The signal strength of an NFC tag’s response during communication.

  • NFC

Mesh Networking:

A network where BLE devices talk to each other to extend signal range across a building.

  • BLE

Monostatic Setup:

Using a single antenna for both transmitting and receiving.

  • General

NDEF:

Standard data format for NFC tags (URLs, contacts).

  • Standard

NFC Forum WLC:

Specification for Wireless Charging over NFC (up to 1W)

  • Standard

NFC Interoperability Testing Laboratory:

 Tool for evaluating compatibility between mobile devices and POS terminals.

  • NFC

NFC Xplorer:

Specialized test system for HF (13.56 MHz) analog and digital conformance.

  • NFC

NFC/WLC Development Kit:

Base Station + Sensor Tag for developing wireless charging on small IoT devices.

  • NFC, WLC

Orientation Sensitivity:

Drop in performance when a tag is rotated against the antenna.

  • General

Passive RFID:

Batteryless tags powered entirely by the reader’s RF field.

  • RFID

Persistence Time:

How long a tag maintains its session state after losing power.

  • RAIN

Population Analysis:

Software mode for testing how multiple tags behave in one field.

  • RAIN

Power Efficiency:

The ratio of power sent from the base station vs. received by the tag.

  • NFC, WLC

Rack:

Industrial enclosure protecting electronics from dust and electrical noise.

  • Hardware

RAIN RFID Alliance:

Industry brand for Passive UHF RFID (ISO 18000-63).

  • Standard

Read Range:

Calculated theoretical distance a tag can be identified in a specific environment.

  • General

Reader Tester:

Simulating a „perfect reader“ to test the logic of physical tags.

  • NFC, RAIN

Resonance Frequency:

The frequency where an antenna is most efficient; indicates material detuning.

  • General

RSSI (Received Signal Strength Indicator):

A measurement of how strong a BLE signal is, used for distance estimation.

  • BLE

SAM Support:

Using Secure Access Modules (MIFARE SAM) to test encrypted chips.

  • Software

Semi-Passive (BAP):

Battery-Assisted Passive; uses a battery to run the chip but reflects RF to talk.

  • RFID

Sensors (Triggers):

Optical or ultrasonic eyes that signal the Xplorer to start a measurement cycle.

  • Hardware

Serialization:

Assigning a unique „license plate“ number to every individual item.

  • General

SGTIN (Serialized GTIN):

A GTIN combined with a unique serial number (the core of RFID retail).

  • Standard

Shielding (Faraday Cage):

Using foil or mesh to block RF waves from reaching certain tags.

  • General

Single-Step Integration:

Testing, encoding, and locking in one physical pass.

  • General

Sniffer Mode:

Real-time analysis of the protocol „talk“ between readers and tags.

  • Software

Substrate:

The material (paper, PET, plastic) that the antenna and chip are mounted on.

  • General

Tag Emulator:

Simulating a „perfect tag“ to test the performance of a physical reader.

  • NFC, RAIN

Tag Sensitivity:

The minimum power ($dBm$) a tag needs to wake up and respond.

  • RAIN

TAM (Tag Auth):

Security commands used in anti-counterfeiting applications.

  • NFC, RAIN

Tamper Evidence:

A tag that breaks its circuit if a package is opened, alerting the system.

  • NFC, RFID

Tari:

Reference time interval for a „0“ bit in reader-to-tag communication.

  • RAIN

TID (Tag Identifier):

A unique, unchangeable ID set by the chip manufacturer at birth.

  • RFID

Trigger Hold Off Distance:

Timing setting to prevent multiple triggers for labels placed close together.

  • Software

Trigger Line:

The signal path from a sensor to the CIU to start an RF pulse.

  • Hardware

Turn-on Power:

The exact power threshold where the tag’s integrated circuit (IC) functions.

  • RAIN

UPH (Units Per Hour):

Throughput metric for production units (often $>100k$).

  • General

User Memory:

A block of memory on an RFID chip where customers can write custom data.

  • RFID

Web Speed:

The travel speed of the label liner (e.g., $100 m/min$).

  • General

WebSocket:

Real-time data protocol used to send test results to external databases.

  • Software

Wet Inlay:

An inlay with a clear adhesive backing, ready to be applied.

  • RFID

WMS (Warehouse Management System):

Software that uses RFID data to manage stock and picking.

  • Software

Xplorer INLINE (RAIN/NFC):

High-speed Production unit for 100% quality testing-  > 300k UPH, encoding & encryption

  • NFC, RAIN

Xplorer Lab (RAIN):

High-precision R&D instrument for characterizing UHF RFID tags and readers.

  • RAIN
